Curved Conical Fireplace

Dress up your living rooms, exterior spaces and other rooms with this fully parametric modern Revit fireplace that includes a log grate for added realism. Change the height of the fireplace to match your ceiling height and configure its additional features like the firebox start height, end height, diameter and exhaust diameter. Additionally, this family comes with a fully customizable exterior chimney that includes parameters like width, height, wall thickness, offset and shape (circular or square) and a parametric log grate with options to change its width, depth and visibility.

This Revit family curved conical fireplace comes with the following customizable parameters and options:

Fireplace and Chimney

Height of fireplace:

• Minimum height: 8′
• Maximum height: 35′

Firebox start height, end height, diameter and exhaust diameter:

• Minimum firebox start height: 6″
• Maximum firebox start height: 1′ 6″

• Minimum clearance height: 1′
• Maximum clearance height: 3′

• Minimum firebox diameter: 3′
• Maximum firebox diameter: 6′

• Minimum exhaust diameter: 6″
• Maximum exhaust diameter: 1′ 6″

Chimney height, width and wall thickness:

• Minimum height: 3′
• Maximum height: 30′

• Minimum width: 1′
• Maximum width: 6′

• Minimum wall thickness: 1″
• Maximum wall thickness: 1′

Chimney offset:

• Minimum offset: 1/4″
• Maximum offset: 30′

Chimney can be turned into a cylindrical chimney

Material parameters for:

• Fireplace
• Brick Moulding
• Grill
• Chimney

Log Grate

Logs Size: This value depends on the overall grate width. The value ranges from 0-2

Grate Overall Width:

• Minimum grate overall width: 1’6″
• Maximum grate overall width: 4′

Grate Overall Depth:

• Minimum grate overall depth: 6″
• Maximum grate overall depth: 1’1″

The following objects can be turned on/off:

• Logs
• Grate

NOTE: if both objects are turned off, the logs will show up by default.

Material parameters for:

• Grate
• Logs

* Hybrid families combine native Revit objects with other 3D applications’ objects for a more organic and realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.
