Patterned Partition Wall Revit Family

• Parametric: Yes
• Hybrid*: No
• Compatible with: Revit 2016 and higher.
• Family type: Generic Model
• Materials/textures: Yes
• Approximate file size: 3.05 MB
• File format: .rfa

This Patterned Partition Wall Revit Family comes with the following customizable parameters and options:

Length of the divider:

• Minimum length: 1′ (not including the frame)

Number of times the pattern repeats horizontally and vertically:

• Minimum number of pattern repeats: 2
• Maximum number of pattern repeats: as many as long as the size of the pattern doesn’t go below 4″

The thickness of the pattern:

• Minimum thickness of pattern: 1/4″
• Maximum thickness of pattern: 4″

Aside from the main parameters described above, this Patterned Partition Wall Revit Family comes with the following additional parameters for further customization:

Frame will adjust automatically depending on the number of times the pattern repeats horizontally and vertically

Frame thickness:

• Minimum frame thickness: 1/2″
• Maximum frame thickness: 1′

Frame width:

• Minimum frame width: 3/8″
• Maximum frame width: 8″

This Partition Wall Revit Family comes with material parameters for:

• Pattern
• Frame

* Hybrid families combine native Revit objects with other 3D applications’ objects for a more organic and realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.

Before purchasing our Revit families and 3D models, make sure you have a software like Winzip or Peazip to unzip files since all our files are delivered in zip format.
