Elliptical Standing Revit Mirror Family With Drawer

• Parametric: Yes
• Hybrid*: No
• Compatible with: Revit 2016 and higher.
• Family type: Furniture
• Materials/textures: Yes
• Approximate file size: 0.58 MB
• File format: .rfa

This Elliptical Standing Revit Mirror Family With Drawer comes with the following customizable parameters and options:

Width and height of mirror+:

• Minimum width: 1’4″
• Maximum width: 4′

• Minimum height: 1’6″
• Maximum height: 1’9 115/256″

+ Measured to the circumference of the ellipse of the Revit mirror family.

Angle of mirror:

• Minimum angle: 0 degrees
• Maximum angle: 45 degrees

You can open/close the drawer by percentage.

NOTE: Position of drawer is fixed as well as its height.

This Elliptical Standing Revit Mirror Family comes with material parameters for:

• Frame
• Drawer
• Mirror
• Bolts

* Hybrid families combine native Revit objects with other 3D applications’ objects for a more organic and realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.

Before purchasing our Revit families and 3D models, make sure you have a software like Winzip or Peazip to unzip files since you will be provided with zip format files.
