Line-Based Family Revit Complex Crown Molding 1

• Parametric: Yes
• Hybrid*: No
• Compatible with: Revit 2016 and higher.
• Family type: Generic Model Line Based
• Materials/textures: No
• Approximate file size: 0.44 MB
• File format: .rfa

This Line-Based Family Revit Complex Crown Molding comes with the following customizable parameters and options:

End angles:

• Maximum inward angle: 60 degrees
• Maximum outward angle: -60 degrees

Minimum height: 4″

Includes the following sizes (family types):

• 4″
• 6″
• 8″
• 10″
• 12″
• 18″
• 24″
• 30″
• 36″
• 48″

IMPORTANT NOTES about this Line-Based Family Revit Complex Crown Molding:

• A LITTLE SLOW TO CREATE since it needs to calculate the details in real time. Once created it won’t slow down the computer.
• You will need to insert this line-based family one wall at a time. It doesn’t work like the Revit wall sweep tool where you can add the molding to all walls in a single click.
• Very small lengths (depends on the size/height of the moulding) with BOTH ends set to inwards cuts won’t have enough room to create the moulding thus it can cause an error.

* Hybrid families combine native Revit objects with other 3D applications’ objects for a more realistic look to the families. The objects coming from other 3D applications are configured to NOT have mesh lines (only outlines) and to display in black.

Before purchasing our Revit families and 3D models, make sure you have a software like Winzip or Peazip to unzip files since all our files are delivered in zip format.
